Specifications
bizhub 554e | bizhub 454e | bizhub 364e | bizhub 284e | bizhub 224e | ||
Type | Desktop Printer / Copier / Scanner | |||||
---|---|---|---|---|---|---|
Copy Resolution | Scan | Main: 600dpi × Sub: 600dpi | ||||
1,800 dpi (equivalent) × 600 dpi | ||||||
Gradation | 256 | |||||
Memory Capacity (Std./Max.) | 2 GB/4 GB | |||||
HDD | 250 GB | |||||
Original Type | Sheets, Books, Objects | |||||
Max. Original Size | A3 (11″ × 17″) | |||||
Output Size | SRA3 to A5, B6S*1, A6S*1 Thick paper, Foolscap*2 (8-1/2″ × 13-1/2″, 200 mm × 330 mm, 8-1/8″ × 13-1/4″, 8-1/2″ × 13″, 8-1/4″ × 13″, 8″ × 13″), 8K, 16K, Long Length Paper (210 × 457.3 mm to 297 × 1,200 mm) | |||||
Image Loss | Max. 4.2 mm or less for top edge (5 mm for thin paper), Max. 3.0 mm or less for bottom edge, Max. 3.0 mm or less for right/left edges * A loss of 4.2 mm each during printing. |
|||||
Warm-Up Time*3 (23°C, std. voltage) *The time required to start printing when both the main power and sub-power switches are turned from OFF to ON. |
22 sec. or less | 25 sec. or less | 20 sec. or less | |||
*The time required to start printing when the main power switch is ON and the sub-power switch is turned from OFF to ON. | 22 sec. or less | 25 sec. or less | 20 sec. or less | 18 sec. or less | ||
First Copy Out Time*4 | 4.1 sec. or less | 4.6 sec. or less | 5.3 sec. or less | 5.9 sec. or less | 6.9 sec .or less | |
Copy Speed (A4 Crosswise) | 55 ppm | 45 ppm | 36 ppm | 28 ppm | 22 ppm | |
Copy Magnification | Fixed Same Magnification | 1:1± 0.5% or less | ||||
Scaling Up | 1: 1.154/1.224/1.414/2.000 | |||||
Scaling Down | 1: 0.866/0.816/0.707/0.500 | |||||
Preset | 3 types | |||||
Zoom | 25 to 400% (in 0.1% increments) | |||||
Lengthwise Crosswise Individual Settings | 25 to 400% (in 0.1% increments) | |||||
Paper Capacity(80g/m2) | Tray 1 | 500 sheets (up to A3) | ||||
Tray 2 | 500 sheets (up to SRA3) | |||||
Multiple Bypass Tray | 150 sheets (up to SRA3) | |||||
Max. Paper Capacity (80g/m2)*5 | 6,650 sheets | 3,650 sheets | ||||
Paper Weight | Tray 1 / 2 | 52 to 256 g/m2 | ||||
Multiple Bypass Tray | 60 to 300 g/m2 | |||||
Multiple Copy | 1 to 9,999 sheets | |||||
Auto Duplex | Paper Size | Width: 100 to 320 mm, Length: 148 to 457.2 mm | ||||
Paper Weight | 52 to 256 g/m2 | |||||
Power Requirements | AC220 to 240 V 9 A (50 to 60 Hz) | AC220 to 240 V 8 A (50 to 60 Hz) | ||||
Max. Power Consumption | 2.0 kW or less | 1.58 kW or less | ||||
Dimensions [W] × [D] × [H] | 615 × 685 × 921 mm (24-1/4″ × 27-1/2″ × 36-1/4″) | 615 × 685 × 779 mm (24-1/4″ × 27-1/2″ × 30-3/4″) | ||||
Weight | Approx. 93 kg (205-1/4 lb) | Approx. 76.5 kg (168-3/4 lb) | ||||
Space Requirements [W] × [D]*6 | 937 × 1,246 mm (37″ × 49″) | 937 × 1,214 mm (37″ × 47-3/4″) |
*2 Set by Customer engineer
*3 May vary depending on the operating environment and usage.
*4 A4 crosswise full size/using the first tray/scanning from the original glass surface.
*5 With options installed.
*6 Without options, with paper trays pulled out, and multiple bypass tray, auxiliary tray and ADF opened.
Type | Embedded | |
---|---|---|
CPU | SOC 800Mhz (DualCore) | |
Memory | Shared with the copier | |
Print Speed | Same as Copy Speed (when using the same original) | |
HDD | 250 GB (Shared witd tde copier) | |
Print Resolution | 1,800 dpi (equivalent) × 600 dpi (at smoothing) or 1,200 dpi × 1,200 dpi (in 1,200 dpi mode) |
|
PDL | PCL 5e/c Emulation, PCL 6 Emulation, PostScript 3 (3016) Emulation, XPS (Ver.1.0) |
|
Protocol | TCP/IP, IPX/SPX (NDSsupport), SMB (NetBEUI), LPD, IPP1.1, SNMP, HTTP | |
Support OS | Windows / Vista / Vista 64bit / 7 / 7 64bit / 8 / 8 64bit / 8.1 / 8.1 64bit Windows Server 2003 / Server 2003 64bit / Server 2003 R2 / Server 2003 R2 64bit / Server 2008 / Server 2008 64bit / Server 2008 R2 / Server 2012 / Server 2012 R2 Mac OS 9.2 / X 10.2 / X 10.3 / X 10.4 / X 10.5 / X 10.6 / X 10.7 / X 10.8 / X 10.9 Linux |
|
Fonts | PCL | 80 Roman fonts |
PS | 137 Roman Type1 fonts | |
Interface | Ethernet (10BASE-T/100BASE-TX/1000BASE-T), USB 1.1, USB 2.0, USB Host |
Type | Full-Colour Scanner | |
---|---|---|
Interface | Ethernet (10BASE-T/100BASE-TX/1000BASE-T) | |
Driver | TWAIN Driver, HDD TWAIN Driver | |
Protocol | TCP/IP (FTP, SMB, SMTP, WebDAV) (IPv4/IPv6) | |
Scanning Speed (Colour/B&W) (300 dpi, A4 Crosswise) |
Simplex | 80 opm |
Duplex | 160 opm | |
Scanning Size | Max. A3 (11″ × 17″) | |
Output Format | TIFF, JPEG, PDF, Compact PDF, XPS, Compact XPS, OOXML (pptx, xlsx*, docx*), Searchable PDF*, PDF/A*, Linearised PDF* *Optional | |
Scanning Resolution | Push | 200dpi / 300dpi / 400dpi / 600dpi |
Pull | 100dpi / 200dpi / 300dpi / 400dpi / 600dpi | |
Main Functions | Scan to E-Mail, Scan to FTP, Scan to BOX (HDD), Scan to PC (SMB), Network TWAIN, Scan to WebDAV, Scan to Me, Scan to Home, Scan to USB, Scan to Scan Server, Scan to Web Service (WSD-Scan), Device Profile for Web Services (DPWS) | |
Other Functions | Multi-Method Send, Authentication at the time of E-Mail send (SMTP authentication, POP before SMTP), S/MIME, Annotation |
Protocol | SMTP, POP |
---|---|
Connection Mode | Full-Mode |
Sending Paper Size | A3, B4, A4 |
Recording Paper Size | Max. A3 |
Resolution | 200 × 100 dpi, 200 × 200 dpi, 400 × 400 dpi, 600 × 600 dpi |
Interface | Ethernet (10BASE-T/100BASE-TX/1000BASE-T) |
Colour | Support Colour Internet Fax |
Format | Send: TIFF-F, Receive: TIFF-F ,Colour/Grey Scale: TIFF (RFC3949 Profile-C) |
Type | Single pass simultaneous duplex system | |
---|---|---|
Support Paper Size | A3 to A6S*1, 11″ × 17″ to 5-1/2″ × 8-1/2″, Foolscap*2 (8-1/2″ × 13-1/2″, 200 mm × 330 mm, 8-1/8″ × 13-1/4″, 8-1/2″ × 13″, 8-1/4″ × 13″, or 8″ × 13″), 8K, 16K | |
Mixed Size | Support | |
Original Set | Centre guide | |
Resolution | 600 dpi support | |
Support Paper Weight | Simplex: 35 to 163 g/m2, Duplex: 50 to 163 g/m2, Mixed Original: 50 to 128 g/m2 FAX Mode: 35 to 163 g/m2 (Simplex), 50 to 163 g/m2 (Duplex) |
|
Paper Capacity | Max. 100 sheets (80 g/m2) | |
Productivity (A4 Crosswise) |
Simplex | Copy (Colour/B&W): 55 opm (600 dpi) Scan (Colour/B&W): 80 opm (300 dpi) |
Duplex | Copy (Colour/B&W):110 opm (600 dpi) Scan (Colour/B&W): 160 opm (300 dpi) |
|
Power Requirements | Supplied from the MFP main body | |
Max. Power Consumption | 74.5 W or less | |
Dimensions [W] × [D] × [H] | 611.2 × 503.6 × 130 mm (24″ × 19-3/4″ × 5″) | |
Weight | Approx. 12 kg (26-1/2 lb) |
*2 Set by Customer engineer
Communication | Super G3 |
---|---|
Compatible Lines | Public Switch Telephone Network, Private Branch Exchange, Fax Communication Line |
Line Density | G3 (8 dot/mm × 3.85 line/mm, 600 × 600 dpi) |
Modem Speed | 2.4 to 33.6 kbps |
Compression | MH/MR/MMR/JBIG |
Sending Paper Size | Max. A3 (Long Lengtd Support: Max.1,000 mm) |
Recording Paper Size | Max. A3 (Long Lengtd Max. 1,000 mm — following the page division —) |
Transmission Speed | Less than 3 sec. (A4, V.34, 33.6 kbps, JBIG) |
Memory | Shared witd the copier |
Number of Abbr. Dials | 2,000 |
Number of Program Dials | 400 |
Number of Group Dials | 100 |
Sequential Multiple Station Transmission | Max. 600 |
Protocol Transmission | SMTP |
---|---|
Sending Paper Size | A3, B4, A4 |
Resolution | 200 × 200 dpi, 400 × 400 dpi, 600 × 600 dpi |
Format | Send: TIFF-F, Receive: TIFF-F, Colour/Grey Scale: TIFF (RFC3949 Profile-C) |
