Product Description
Specifications
| Type | Console | |
|---|---|---|
| Resolution | 1,200 × 1,200 dpi | |
| Gradation | 256 | |
| Memory Capacity | DIMM | 768 MB |
| HDD | 250 GB | |
| Image position accuracy*1 (Front-to-back registration accuracy) |
Front-to-back shift amount (XY component) | 0.6 mm or less |
| Output Size *S: Short edge feed |
SRA3, A3 to B5, A5S*, Tab paper, Custom (182 × 139 to 324 × 463 mm) |
|
| Warm-Up Time | 460 sec. or less | |
| Paper Capacity (80 g/m2) | Standard | 1,500 sheets × 2 |
| Paper Weight | Standard | 40 to 300 g/m2 (Limitations to paper types apply) |
| Option | 40 to 350 g/m2 (Only available for middle tray of PF-703 and PF-706) | |
| Power Requirements | 220 to 240 V/25 A (50 to 60Hz) | |
| Max. Power Consumption*2 | 12 kW or less | |
| Dimensions [W] × [D] × [H] | 2,815 × 910 × 1,020 mm (111″ × 35-3/4″ × 40-1/4″)*3 5,450 × 910 × 1,454 mm (214-3/4″ × 35-3/4″ × 57-1/4″)*4 |
|
| Weight | 768 kg (1,693-1/4 lb)*3 | |
| Space Requirements [W] × [D] | 3,000 × 2,060 mm (118-1/4″ × 81-1/4″)*3 | |
- *1 Prerequisites:
- 1. Must be a rectangular piece of paper that is uniform in size.
2. Image position adjustment has been made to match the paper. - *2
- PF-703 + PF-703 + PF-703 + bizhub PRESS 1250P + RU-510 + TD-501 + bizhub PRESS 1250P + RU-509 + HM-102 + RU-510 + FD-503 + SD-506 + PB-503 + FS-532
- *3
- bizhub PRESS 2250P (bizhub PRESS 1250P + RU-510 + TD-501 + bizhub PRESS 1250P)
- *4
- PF-730 + bizhub PRESS 1250P + RU-510 + TD-501 + bizhub PRESS 1250P + RU-510 + LS-505 + FS-532
| Type | Embedded | |
|---|---|---|
| CPU | Pentium G6950 2.8 GHz | |
| Memory | 2 GB | |
| HDD | 250 GB 3.5 inch SATA | |
| Print Speed | 250 ipm (A4/Letter), 140 ipm (A3), 136 ipm (Ledger) | |
| Print Resolution | 1,200 × 1,200 dpi, 600 × 600 dpi | |
| PDL | PCL5e/6, PostScript3 (3019), PDF Ver1.7, TIFF Ver. 6 Emulation, PPML (Ver2.2) | |
| Protocol | TCP/IP, IPX/SPX (NDS support), SMB (NetBEUI), IPP, EtherTalk | |
| Support OS | PCL | Windows Server 2003 Standard / Enterprise, Windows Server 2003 Standard (x64) / Enterprise (x64), Windows Server 2008 / 2008 (x64) / 2008R2 (x64), Windows Server 2012 / 2012 (x64) Windows Vista / Vista (x64), Windows 7 / 7 (x64), Windows 8 / 8 (x64), Windows 8.1 / 8.1 (x64) |
| PS3 | Windows Server 2003 Standard / Enterprise, Windows Server 2003 Standard (x64) / Enterprise (x64), Windows Server 2008 / 2008 (x64) / 2008R2 (x64), Windows Server 2012 / 2012 (x64) Windows Vista / Vista (x64), Windows 7 / 7 (x64), Windows 8 / 8 (x64), Windows 8.1 / 8.1 (x64) Mac OS X 10.6, X 10.7, X 10.8, X 10.9 CUPS (by PS PPD) |
|
| Fonts | PCL | 80 fonts |
| PS3 | 136 fonts | |
| Interface | 10Base-T/100Base-TX/1000Base-T, USB2.0 (Hi-Speed) | |
