Bizhub C3110/C3100P

02
01030405

Bizhub C3110/C3100P

Choice of MFP and printer models
Customers can choose between bizhub C3110 MFP model which combines printing, copying, scanning and faxing in a single unit, or the more compact bizhub C3100P printer model with printing function only.

Compact body for easy placement just about anywhere
With a width of just 446.5mm and depth of 544 mm, the bizhub C3110/C3100P are small enough to be conveniently placed on a desktop.

31 ppm (A4) high-speed outputs in colour and monochrome
The bizhub C3110/C3100P boost productivity with high-speed outputs of 31 ppm (A4) in both colour and monochrome .

850-sheet paper capacity for fewer paper replenishments
Despite their compact sizes, the bizhub C3110/C3100P offer a maximum 850-sheet paper capacity (with the 100-sheet manual bypass tray and optional 500-sheet paper cassette attached) to deliver outstanding performance with ample paper. Legal size paper* is also supported for larger size outputs.

1,200 dpi high-resolution mode for beautiful reproductions of small text
The bizhub C3110/C3100P adopt 1,200 dpi high-resolution mode, providing outstanding reproductions of small text and very thin lines for producing outputs of highly elaborate diagrams and small print documents.

Mobile and cloud compatible PageScope Mobile*1
The bizhub C3110/C3100P are PageScope Mobile compatible, allowing direct printing from and saving scanned data*2 to Android devices and iPhones/iPads. In addition, PageScope Mobile offers smooth connectivity with cloud services for printing data saved in cloud or saving scanned data to cloud.

Direct outputs of USB memory device data*1 for quick PC-less printing
Like the A3 bizhub MFPs, the bizhub C3110/C3100P are equipped with a port for USB memory devices, allowing data in USB memory devices to be printed directly from the main unit. Jobs in a hurry can be printed quickly and easily without having to access a PC.

Various scan & send functions for information sharing and paperless office (bizhub C3110 only)
The bizhub C3110 MFP promotes information sharing and a paperless office with a variety of scanning methods for sending and saving data, including via e-mail, and to PCs, FTP servers and USB memory devices.

Other convenient functions for the bizhub C3110 only
*Convenient ID (card) copy
Both the front and back sides of small card size documents can be scanned and copied onto one sheet of paper to enhance convenience and save paper.
*Standard equipped duplex ADF for high-speed scanning of double-sided documents
*Super G3 faxing is optionally available

Simitri HD toner with biomass for low environmental impact
The bizhub C3110/C3100P adopt Simitri HD toner which offers less environmental impact during its production and reduces power consumption with low temperature fusing. The toner is also carbon neutral as it is produced with plant-based biomass materials.

One-touch power saving keys for easy energy savings
The bizhub C3110/C3100P let you save power easily by switching to Sleep mode or ErP Auto Power Off mode with a push of a key on the control panel.
*C3110  : Sleep mode: Long push of Scan button
ErP Auto Power Off mode: Long push of Copy button
C3100P: Sleep mode: Short push of Power button
ErP Auto Power Off mode: Long push of Power button

Recycled materials and recycled PC for main unit
Environmentally conscious recycled PC is used in various locations of the main unit.

Increased functionality with PageScope Enterprise Suite
The bizhub C3110/C3100P are compatible with PageScope Enterprise Suite (PSES)*1 which provides integrated management of all networked MFPs and printers from a single server. In addition to cooperative network management of the bizhub C3110/C3100P and A3 MFPs, PSES offers a variety of powerful functions including account management according to device, user and department, and increased security by authentication management*2 and privilege management. Furthermore, centralised device management, which reduces administrator burden, and Optimised Print Services*3, which proposes the optimal placement of office devices, allow you to use the devices efficiently while saving costs.

Konica Minolta’s Emperon controller with advanced printing technology
Emperon printer controller developed with Konica Minolta’s proprietary technologies provides a high-speed, high-quality and highly functional printing environment. High quality outputs are realised with page description languages such as PCL, PostScript and XPS, and high-speed processing of file formats such as JPEG, PDF and OOXML. In addition to regular printer interface and network printing, direct printing from USB memory devices* is also supported for smoother output operations.

Main unit authentication and IC card authentication
In addition to main unit authentication, various IC card authentication devices* are supported including Konica Minolta’s AU-201*. Connecting PageScope Authentication Manager* allows integrated user management in mixed environments with A3 bizhub devices.

Scheduled to obtain ISO/IEC 15408 certification, ISO’s Common Criteria for IT security
Installing the optional hard disk will make the bizhub C3110 compatible with ISO/IEC 15408 certification. (Scheduled to obtain certification in October 2014.)

download

Categories: ,

Product Description

Specifications

General Specifications
bizhub C3110 bizhub C3100P
Type Desktop Printer / Copier / Scanner Desktop Printer
Colour Support Full Colour
Copy Resolution Scan 600 dpi × 300 dpi (Max.: 600 dpi)
Print 600 dpi × 600 dpi
Gradation 256
Memory Capacity (Std./Max.) 1GB / 2 GB (Optional)
HDD 320 GB (Optional)
Original Type Sheets, Books, Objects (Max. weight 3 kg)
Max. Original Size A4 or Legal (ADF only)
Output Size Standard Tray: A4S*1 to A6S*1, B5S*1
Multiple Bypass Tray: Legal (8.5″ × 14″), A4S*1 to A6S*1, B5S*1,
Envelope*2 (10 sheets or less)
Image Loss Copy Max. 4.0 mm for top / bottom / right / left edges
Print Max. 4.2 mm for less for top / bottom / right / left edges
Warm-Up Time*3 36 sec. or less
First Copy / Print Out Time*4 Colour 15 / 12.9 sec. or less —/ 12.9 sec. or less
B/W 13 / 12.9 sec. or less —/ 12.9 sec. or less
Copy / Print Speed Colour / B&W 31 ppm (A4 Crosswise)
Copy Magnification Fixed Same Magnification 1:1±1.0% or less
Scaling Up 1: 1.15 / 1.41 / 2.00 / 4.00
Scaling Down 1: 0.86 / 0.70 / 0.50 / 0.25
Preset 3 types
Zoom 25 to 400% (in 1.0% increments)
Lengthwise Crosswise Individual Settings 25 to 400% (in 1.0% increments)
Paper Capacity (80g/m2) Standard Tray 250 sheets
Multiple Bypass Tray 100 sheets (up to Legal)
Max. Paper Capacity (80 g/m2) 850 sheets
Paper Weight*5 Standard Tray 60 to 210 g/m2
Multiple Bypass Tray 60 to 210 g/m2
Multiple Copy 1 to 99 sheets
Auto Duplex Type Non-Stack
Paper Size Legal, B5S*1, A4S*1
Paper Weight 60 to 210 g/m2
Power Requirements 220 to 240 V 4.6 A (50 to 60 Hz)
Max. Power Consumption 1.2 kW or less
Dimensions [W] × [D] × [H] 446.5 × 544 × 500 mm (17-1/2″ × 21-1/2″ × 19-3/4″) 446.5 × 544 × 350 mm (17-1/2″ × 21-1/2″ × 13-3/4″)
Weight Approx. 34.3 kg (75-1/2 lb) Approx. 28.3 kg (62-1/2 lb)
Space Requirements*6 [W] × [D] 723 × 866 mm (28-1/2″ × 34″)
*1 S: Short edge feed
*2 Wrinkling and printing errors may occur depending on the envelope type, storage and printing environment.
*3 Warm-up time may vary depending on the operating environment and usage.
The time required to start printing when both the main power and sub-power switches are turned from OFF to ON. (23°C, std. voltage)
*4 A4 crosswise full size / using the standard tray / scanning from the original glass surface.
*5 Inkjet paper is not supported.
*6 With the multiple bypass tray and paper tray open.
Printer Specifications
bizhub C3110 bizhub C3100P
Type Embedded
Memory Capacity (Std./Max.) 1 GB / 2 GB (Optional)
Print Speed Same as Copy Speed (when using the same original)
Print Resolution Default mode: 600 dpi × 600 dpi
High Quality mode*1: 1,200 dpi × 1,200 dpi
PDL PCL5e/c Emulation,
PCL6 (XL Ver.3.0) Emulation,
PostScript 3 (3016) Emulation,
XPS (Ver.1.0), PPML/GA2.2,
PPML VDX, Open XPS,
PDF 1.7
PCL5e/c Emulation,
PCL6 (XL Ver.3.0) Emulation,
PostScript 3 (3016) Emulation ,
XPS (Ver.1.0)*, PPML/GA2.2*,
PPML VDX*, Open XPS*,
PDF 1.7* *With HDD installed
Protocol TCP/IP, SMB, IPP1.1, SNMP
Support OS PCL Windows Vista (x32, x64) / 7 (x32, x64) / 8 (x32, x64) / 8.1 (x32, x64)
Windows Server 2003 (x32, x64)/ Server 2008 (x32, x64) /
Server 2008 R2 / Server 2012 / Server 2012 R2
PS Windows Vista (x32, x64) / 7 (x32, x64) / 8 (x32, x64) / 8.1 (x32, x64)
Windows Server 2003 (x32, x64)/ Server 2008 (x32, x64) /
Server 2008 R2 / Server 2012 / Server 2012 R2
Mac OS X 10.2 / X 10.3 / X 10.4 / X 10.5 / X 10.6 / X 10.7 / X 10.8 / X10.9
Linux
XPS Windows Vista (x32, x64) / 7 (x32, x64) / 8 (x32, x64) / 8.1 (x32, x64)
Windows Server 2003 (x32, x64)/ Server 2008 (x32, x64) /
Server 2008 R2 / Server 2012 / Server 2012 R2
Fonts PCL 80 Roman fonts
PS 137 Roman Type1 fonts
Interface Ethernet (10BASE-T / 100BASE-TX / 1000BASE-T)
USB 1.1, USB 2.0, USB Host
*1 Output speed will be reduced.
Scanning Specifications (bizhub C3110 only)
Type Full-Colour Scanner
Interface Ethernet (10BASE-T / 100BASE-TX / 1000BASE-T), USB Host
Protocol TCP/IP (FTP, SMB, SMTP)
Scanning Speed*1 (A4, Colour / B&W) Simplex 30 opm
Duplex 12 opm
Scanning Size A4 or Legal (ADF only)
Output Format TIFF, JPEG, PDF, Compact PDF, XPS
Scanning Resolution (Colour / B&W) Flatbed scan: 600 dpi × 300 dpi, 600 dpi × 600 dpi
ADF scan: 600 dpi × 300 dpi
Scan to xx (Flatbed scan / ADF scan):
200 dpi × 200 dpi, 300 dpi × 300 dpi
(With HDD installed: 400 dpi × 400 dpi, 600 dpi × 600 dpi (Max.))
Network Twain (Flatbed scan / ADF scan):
150 dpi × 150 dpi, 300 dpi × 300 dpi, 600 dpi × 600 dpi,
1,200 dpi × 1,200 dpi, 2,400 dpi × 2,400 dpi,
4,800 dpi × 4,800 dpi
Support OS*2 Windows Vista (x32, x64) / 7 (x32, x64) / 8 (x32, x64) / 8.1 (x32, x64)
Windows Server 2003 (x32, x64)/ Server 2008 (x32, x64) /
Server 2008 R2 / Server 2012 / Server 2012 R2
*1 B/W: 600 dpi × 300 dpi Colour: 300 dpi × 300 dpi
*2 TWAIN driver supported OS
Fax Kit FK-512 (bizhub C3110 only) (Optional)
Communication Super G3
Communication Lines Public Switch Telephone Network, Private Branch Exchange, Fax Communication Line
Line Density G3 (8 dot/mm × 3.85 line/mm, 600 × 600 dpi)
Modem Speed 2.4 to 33.6 kbps
Compression MH / MR / MMR / JBIG
Sending Paper Size Max. A4 or Legal (Long Length Support: Max.1,000 mm (ADF))
Recording Paper Size Max. A4 or Legal
(Long Length Max. 1,000 mm — following the page division —)
Transmission Speed Less than 3 sec. (A4, V.34, 33.6 kbps, JBIG)
Memory Shared with the copier
Number of Abbr. Dials 2,000
Number of Group Dials 100
Sequential Multiple Station Transmission Max. 400
Paper Feed Unit PF-P14 (Optional)
Support Paper Type (Weight) 60 to 90 g/m2
Support Paper Size Legal, Letter, A4, B5
Paper Capacity (80 g/m2) 500 sheets
Power Requirements Supplied from the MFP main body
Dimensions [W] × [D] × [H] 447 × 529 × 117 mm (17-1/2″ × 20-3/4″ × 4-1/2″)
Unit Configuration Paper tray, 1 level
Weight Approx. 7.5 kg (16-1/2 lb)
Authentication Unit (IC Card type) AU-201 (Optional)
Applicable Card ISO 14443 TypeA, FeliCa-based noncontact IC card
Interface USB 1.1 or later
Power Supply Power received from USB port
Dimensions [W] × [D] × [H] 92 × 64 × 16 mm (3-3/4″ × 2-1/2″ × 3/4″)
Weight Approx. 120 g (264-1/2 lb)
