Bizhub 4020/3320

All-round A4 monochrome output devices
The bizhub 4020 / 3320 are optimal for small offices that require high multifunctional A4 performance within a limited space. And optional Wi-Fi connectivity allows them to be set up as network devices in more locations without the trouble of installing LAN cables.

Compact enough to fit almost anywhere
The 489 mm wide × 452 mm deep bizhub 4020 and 389 mm wide × 472 mm deep bizhub 3320 are compact enough to be placed even on a desktop with little space.

Colour scanner
Scan at high speeds of 19 opm in colour and 41 opm (42 opm for 3320) in monochrome. The scanner even supports legal size paper*1 and the standard equipped RADF (Recirculating Automatic Document Feeder)*2 boosts scanning performance even further for high volume documents.
*1 Scanning from the platen (document glass surface) is supported up to A4 paper only for the bizhub 3320.
*2 ADF (Automatic Document Feeder) for the bizhub 3320.

High-speed , high quality outputs
Get high-speed outputs of 40 ppm (A4) with the bizhub 4020 and 33 ppm (A4) with the bizhub 3320 at 600 × 600 dpi. In addition, 1,200 × 1,200 dpi high-resolution is also available for higher quality outputs. PCL6 emulation – often used for business – and PostScript3 emulation are also supported to provide an enhanced range of outputs.

Standard fax function
In addition to copying, printing and colour scanning, Super G3 faxing comes standard for the bizhub 4020 / 3320 for reliable all-round performance in a compact design.

Mopria Print Service
Devices running Android 4.4 or later OS versions can output printing without going through a printer driver.

Konica Minolta Print Service
Standard Android print functions can print directly to bizhub.
* Android version 4.4 or later.

PageScope Mobile for bizhub to mobile device connectivity
Use PageScope Mobile for Android or PageScope Mobile for iPhone/iPad free of charge from Konica Minolta for smooth wireless connectivity with mobile devices such as smartphones and tablet devices. PDFs and image data*1 stored in a mobile device can be printed wirelessly from a bizhub MFP/printer, and scanned data from the bizhub MFP can be viewed from a mobile device.
*1 Printable formats: PDF / TIFF / JPEG / XPS

Increase paper capacity with optional cassettes
The bizhub 4020 can be fitted with up to three optional 550-and/or 250-sheet paper feeding units for a maximum capacity of 2,000 sheets within the same compact footprint. The bizhub 3320 offers a maximum paper capacity of 850 sheets.

Direct USB printing (bizhub 4020 only)
Print data stored in USB memory devices can be printed directly from the USB port on the front of the bizhub 4020’s control panel.

Optional barcode and Unicode printing
The bizhub 4020 is available with an optional card that expands its printing capabilities to include barcode fonts and Unicode fonts.

Optimal device placement for lower TCO and environmental performance
Konica Minolta’s Optimised Print Services (OPS) promotes greater business efficiency through optimal device placement and reduced TCO. Optimally placing more eco-conscious devices also reduces power costs.

Increase productivity with an integrated device management solution
With PageScope Enterprise Suite 3.1, administrators can enhance efficiency by centrally managing the bizhub 4020 /3320 and all other networked digital devices including A3 MFPs.

Cost-effective A4 monochrome outputs
The bizhub 4020 / 3320 deliver outstandingly low TCO by saving both initial costs and running costs.

Also compact for low environmental impact
The bizhub 4020 / 3320 employ functions that help reduce toner and paperuse during printing.
They are also certified by numerous environmental programmes and support environmental systems from around the world, including the International Energy Star standard, Germany’s Blue Angel Mark, The Eco Declaration – Europe’s declaration system for IT products.

download

Product Description

Specifications

General Specifications
bizhub 4020 bizhub 3320
Type Desktop Printer / Copier / Scanner
Copy Resolution Scan Main: 600 dpi × Sub: 600 dpi
Print Main: 600 dpi × Sub: 600 dpi
Gradation 256
Memory Capacity (Std./Max.) 512 MB/2.5 GB 256 MB/256 MB
HDD 160 GB (Opt.)
Original Type Sheets, Books, Objects
Max. Original Size A4 or Legal (8-1/2″ × 14″)
Output Size Legal, Letter, A4 to A6
Custom: 76.2 × 127 mm to 216 × 356 mm
Image Loss Copy Max. 4.0 mm ±0.2 mm or less for top/bottom/right/left edges
Print Max. 4.0 mm ±0.2 mm or less for top/bottom/right/left edges
Warm-Up Time1 95 sec. or less 76 sec. or less
First Copy Out Time2 6.5 sec. or less
Copy Speed (A4) 40 ppm 33 ppm
Copy Magnification Fixed Same Magnification 1: 1.000 ±0.5% or less
Scaling Up 1: 1.15 / 1.22 / 1.41
Scaling Down 1: 0.87 / 0.82 / 0.70
Preset 3 types
Zoom 25 to 400% (in 1% increments)
Lengthwise Crosswise Individual Settings
Paper Capacity(75 g/m2) Tray 1 250 sheets (up to Legal)
Multiple Bypass Tray 100 sheets (up to Legal) 50 sheets (up to Legal)
Max. Paper Capacity (75g/m2) 2,000 sheets 850 sheets
Paper Weight Tray 1 60 to 120 g/m2 60 to 90 g/m2
Multiple Bypass Tray 60 to 163 g/m2
Multiple Copy 1 to 999 sheets
Auto Duplex Type Non-Stack
Paper Size Legal, Letter, A4
Paper Weight 60 to 90 g/m2
Power Requirements AC220 to 240 V 4.0 A (50 to 60 Hz)
Max. Power Consumption 972 W or less 926 W or less
Dimensions [W] × [D] × [H] 489 × 452 × 502 mm (19-1/4″ × 17-3/4″ × 19-3/4″) 389 × 472 × 468 mm (15-1/4″ × 18-1/2″ × 18-1/2″)
Weight Approx. 21.8 kg (48 lb) Approx. 20 kg (44 lb)
Space Requirements3 [W] × [D] 664 × 856.8 mm (26-1/4″ × 33-3/4″) 564 × 876.8 mm (22-1/4″ × 34-1/2″)
1 Warm-up time may vary depending on the operating environment and usage.
The time required to start printing when both the main power andsub-power switches are turned from OFF to ON. (23°C, std. voltage)
2 A4 full size/using the first tray/scanning from the original glass surface.
3 Without options, with paper trays pulled out, and multiple bypass tray, auxiliary tray and ADF opened.
Printer Specifications
bizhub 4020 bizhub 3320
Type Embedded
CPU 6170 (800 MHz)
Memory Shared with the copier
Print Speed Same as Copy Speed (when using the same original)
HDD Shared with the copier
Print Resolution Default mode: 600 dpi × 600 dpi
High Quality mode *1: 1‚200 dpi × 1‚200 dpi
Enhanced mode *1: 2‚400 dpi equiv.
PDL PCL5 Emulation, PCL6 Emulation, PostScript3 Emulation, XPS
Protocol TCP/IP, IPP1.1, SNMP, HTTP
Support OS PCL Windows Vista (x32, x64) / 7 (x32, x64) / 8 (x32, x64) / 8.1 (x32, x64) /
Windows Server 2003 (x32, x64) / Server 2008 (x32, x64) /
Server 2012 (x32, x64)
PS Windows Vista (x32, x64) / 7 (x32, x64) / 8 (x32, x64) / 8.1 (x32, x64)
Windows Server 2003 (x32, x64) / Server 2008 (x32, x64) / Server 2012 (x32, x64)
Mac OS X 10.6 / X 10.7 / X 10.8 / X 10.9
Linux
XPS Windows Vista (x32, x64) / 7 (x32, x64) / 8 (x32, x64) / 8.1 (x32, x64)
Windows Server 2008 (x32, x64) / Server 2012 (x32, x64)
Fonts PCL 89 Roman fonts
PS 91 Roman Type1 fonts
Interface Ethernet (10BASE-T / 100BASE-TX / 1000BASE-T),
USB 2.0, USB Host,
IEEE1284 (Opt.)
Ethernet (10BASE-T / 100BASE-TX), USB 2.0
1 Output speed will be reduced.
Scanning Specifications
bizhub 4020 bizhub 3320
Type Full-Colour Scanner
Interface Ethernet (10BASE-T / 100BASE-TX)
Driver TWAIN Driver
Protocol TCP/IP (FTP, SMB, SMTP)
Scanning Speed (A4, 300 dpi) Simplex B&W/Colour: 41/19 opm B&W/Colour: 42/19 opm
Duplex B&W/Colour: 18/8 opm
Scanning Size Max. A4 or Legal (8-1/2″ × 14″) Max. A4 or Letter
Output Format TIFF, JPEG, PDF, XPS
Scanning Resolution Push 200dpi / 300dpi / 400dpi / 600dpi
Pull 200 × 100 dpi / 300 dpi / 400 dpi / 600 dpi
Main Functions Scan to E-Mail, Scan to FTP, Network TWAIN, Scan to USB, Scan to Web Service (WSD Scan), Device Profile for Web Services (DPWS) Scan to E-Mail, Scan to FTP, Network TWAIN, Scan to Web Service (WSD Scan), Device Profile for Web Services (DPWS)
Other Functions Multi-Method Send, Authentication at the time of E-Mail send (SMTP authentication,POP before SMTP)
Fax Specifications
Communication Super G3
Compatible Lines Public Switch Telephone Network, Private Branch Exchange,
Fax Communication Line
Line Density G3 (8 dot/mm × 3.85 line/mm, 600 × 600 dpi)
Modem Speed 2.4 to 33.6 kbps
Compression MH / MR / MMR / JBIG
Sending Paper Size Max. A4 or Legal
Recording Paper Size Max. A4 or Legal
Transmission Speed Less than 3 sec. (A4, V.34, 33.6 kbps, JBIG)
Memory Shared with the copier
Number of Abbr. Dials 500
Sequential Multiple Station Transmission Max. 400
Reverse Automatic Document Feeder (For bizhub 4020)
Type Circulatory duplex system
Support Paper Size Legal, Letter, A4 to A6
Custom: 105 × 148 mm to 216 × 356 mm)
Mixed Size Support
Original Set Centre guide
Resolution 600 dpi support
Support Paper Weight 52 to 120 g/m2
Paper Capacity (75 g/m2) Max. 50 sheets
Productivity (A4) Simplex Copy B&W: 40 opm
Scan B&W: 41 opm, Colour: 19 opm
Duplex Copy B&W: 18 opm
Scan B&W: 18 opm, Colour: 8 opm
Automatic Document Feeder (For bizhub 3320)
Type Simplex system
Support Paper Size Legal, Letter, A4 to A6
Custom: 105 × 148 mm to 216 × 356 mm)
Mixed Size Support
Original Set Centre guide
Resolution 600 dpi support
Support Paper Weight 52 to 120 g/m2
Paper Capacity (75 g/m2) Max. 50 sheets
Productivity (A4) Simplex Copy B&W: 33 opm
Scan B&W: 42 opm, Colour: 19 opm
Paper Feeder Unit PF-P11 (Optional)
Support Paper Type (Weight) 60 to 120 g/m2
Support Paper Size Legal, Letter, A4, B5, A5
Custom: 105 × 148 mm to 216 × 356 mm
Paper Capacity (75 g/m2) 250 sheets
Power Requirements Supplied from the MFP main body
Dimensions [W] × [D] × [H] 389 × 382 × 77 mm (15-1/4″ × 15″ × 3″)
Unit Configuration Paper tray, 1 level
Weight Approx. 4.2 kg (9-1/4 lb)
Paper Feeder Unit PF-P12 (Optional)
Support Paper Type (Weight) 60 to 120 g/m2
Support Paper Size Legal, Letter, A4, B5, A5
Custom: 105 × 148 mm to 216 × 356 mm
Paper Capacity (75 g/m2) 550 sheets
Power Requirements Supplied from the MFP main body
Dimensions [W] × [D] × [H] 389 × 382 × 109 mm (15-1/4″ × 15″ × 4-1/4″)
Unit Configuration Paper tray, 1 level
Weight Approx. 4.7 kg (9-1/4 lb)
